Infrico Self-Service has been designed to allow food service in the smallest space possible, or the creation of independent zones depending on the type of food, so the user can freely serve himself without any queue. This product is equip for hotels and cafeterias with very careful finishing's in the standard version and wide customization possibilities.
General Strengths
Interiors have joints with rounded corners (wide radius for easy cleaning).
Drain inside the cabinet for liquids evacuation.
Greater precision in temperature control. Easier to adjust the temperature range we want to achieve.
LED lighting incorporated, reducing energetic consumption between 80% and 90% respect to a traditional light bulb.
All condenser units are tested 100%, in helium chambers to refrigerant leak detections.
Infrico is AENOR audited and certified by internationally recognized firm.
ISO 9001:2015 (Quality); ISO 14001:2015 (Environmental); OSHAS 18001:2007 (Prevention and Worker Safety).
Audited and Certified by INTERTEK for compliance with UL 471 and NSF 7
Key Features:
Exterior
AISI 304 stainless steel exterior.
Lift-up tempered double glass system (6-15-5).
Standard shelves and solid back door.
Interior
AISI 304 stainless steel interior.
Drain inside the cabinet.
Wide rounded corners for easy cleaning.
Stamped bottom.
Interior LED lighting.
Door
Doors with integrated double handle and blocked opening hinge.
Interior of door inserted with a three-chamber door gasket easily removable.
Large door clearance of 1190x560 mm (VC1400).
Large door clearance of 1815x560 mm (VC2010).
Small door clearance of 550x510 mm.
Optionally double glazed small door (6-15-5).
Insulation
Insulation by free CFC’s polyurethane, foam high-pressure injected with density 40 Kg/m3
Zero ODP and Low GWP.
Shelves
(2) plastic covered steel interior shelves of 600x400 mm.
Height adjustable.
Guides and shelves easily removable for cleaning.
Refrigeration
Temperature and defrost regulated by a digital controller.
Automatic defrost.
Ventilated condensation system.
Forced evaporation system.
Stainless steel evaporative tray.
Evaporators treated with anti-corrosion polyester Epoxy.
Climatic class 4 (30ºC, 55%RH).
Specifications:
Dimensions: L1384 x D800 x H1060 mm
Weight: 156 kg
Shelves: 2
Doors: 2
Exposure: 0.85 m2
Cabinet Volume: 400L
Gross Volume: 1174L
Temperature: +3ºC/+6ºC R
Electrical Connection: 230V/ 1ph/60Hz
Gas Charge: 380 gr
Infrico
Infrico was born in 1986 with a clear objective: to generate the best cooling solutions adapted to the specific needs of each client. Technological vanguard, certified quality and the excellence of its products are the guarantees to support its commitment to innovation and that have positioned it as absolute leaders in the commercial refrigeration equipment.
